LED Waterproof Luminaire

Installation Guide Technical Data Body & Glass Aluminum Anodized Body & Polycarbonate Glass Operating Voltage 220 V - 240 V AC 50 - 60 Hz Operating Heat -30°C / +70°C Kelvin 3000K - 4000K - 6500K Effiency PFC >%95 Body Aluminum Anodized Body Diffuser Polycarbonate Glass Optic - Source of Light Mid Power LED IP Protection Class IP65 Impact Resistance (IK) IK10 Input Voltage 220-240V AC 50/60 Hz Max. Voltage Strength 2 kV Driving Current 700 mA Power Factor >0.95 Color Rendering Index >80 Led Life 100.000 Hour Usage Surface Mounted

---

Product Code VL569018-LP

Power 18W

Lumen 1.850

Weight 0,72

Dimensions(mm) 620 x 54 x 78

Datasheet / Datasheet

LDT / Ldt

---

Product Code VL569030-LP

Power 30W

Lumen 3.051

Weight 1,16

Dimensions(mm) 1023 x 54 x 78

Datasheet / Datasheet

LDT / Ldt

---

Product Code VL569036-LP

Power 36W

Lumen 3.687

Weight 1,32

Dimensions(mm) 1190 x 54 x 78

Datasheet / Datasheet

LDT / Ldt

---

Product Code VL569045-LP

Power 45W

Lumen 4.518

Weight 1,32

Dimensions(mm) 1190 x 54 x 78

Datasheet / Datasheet

LDT / Ldt

---

Product Code VL569055-LP

Power 55W

Lumen 5.627

Weight 1,66

Dimensions(mm) 1500 x 54 x 78

Datasheet / Datasheet

LDT / Ldt

---
