Square Case LED Globe Luminaire

Installation Guide Technical Data Body ABS Body Diffuser Polycarbonate Glass Optic - Source of Light Mid Power LED IP Protection Class IP65 Impact Resistance (IK) IK10 Input Voltage 220-240V AC 50/60 Hz Max. Voltage Strength 2 kV Driving Current 700 mA Power Factor >0.9 Color Rendering Index >80 Led Life 100.000 Hour Usage Surface Mounted Body ABS Body Diffuser Polycarbonate Glass Optic - Source of Light Mid Power LED IP Protection Class IP40 Impact Resistance (IK) IK10 Input Voltage 220-240V AC 50/60 Hz Max. Voltage Strength 2 kV Driving Current 700 mA Power Factor >0.9 Color Rendering Index >80 Led Life 100.000 Hour Usage Surface Mounted

---

Product Code VL910010

Power 10W

Lumen 920

Weight 0,27

Dimensions(mm) 200 x 200 x 85

Datasheet / Datasheet

LDT / Ldt

---

Product Code VL911010

Power 10W (Radar Sensörlü)

Lumen 920

Weight 0,31

Dimensions(mm) 200 x 200 x 85

Datasheet / Datasheet

LDT / Ldt

---

Product Code VL910020

Power 20W

Lumen 2.050

Weight 0,38

Dimensions(mm) 260 x 260 x 66

Datasheet / Datasheet

LDT / Ldt

---

Product Code VL911020

Power 20W (Radar Sensörlü)

Lumen 2.050

Weight 0,42

Dimensions(mm) 260 x 260 x 66

Datasheet / Datasheet

LDT / Ldt

---

Product Code VL911220

Power 20W (Haraket Sensörlü)

Lumen 2.050

Weight 0,42

Dimensions(mm) 260 x 260 x 75

Datasheet / Datasheet

LDT / Ldt

---

Product Code VL912020

Power 20W (Haraket Sensörlü + Kitli)

Lumen 2.050

Weight 0,50

Dimensions(mm) 260 x 260 x 75

Datasheet / Datasheet

LDT / Ldt

---
